Becker Vakum – Roots Booster Tip Pompalar
| Datasheet | MODEL | Debi [m3/h] 50/60 Hz | Vakum [mbar rel.] 50/60 Hz | Motor Gücü [KW] 50/60 Hz |
|---|
|
|
|
|
||
|---|---|---|---|---|
 |
RBP 500 | 500/600 | ∆p 60/60 mbar | 2.2/2.6 |
|
RBP 1000 | 1000/1200 | ∆p 60/60 mbar | 4.0/4.8 |
|
RBP 2000 | 2000/2400 | ∆p 60/60 mbar | 5.5/6.6 |
| Datasheet | MODEL | Debi [m3/h] 50/60 Hz | Vakum [mbar rel.] 50/60 Hz | Motor Gücü [KW] 50/60 Hz |
|---|
|
|
|
|
||
|---|---|---|---|---|
|
BCV 100 | 100/120 | ∆p 50/50 mbar | 2.2…3.0/2.2…3.0 |
|
BCV 150 | 1000/1200 | ∆p 100/100 mbar | 3.0…4.0/3.0…4.0 |
|
BCV 300 | 275/325 | ∆p 150/150 mbar | 5.5…7.5/5.5…7.5 |
Becker Vakum – Yaglı Tip Vakum Pompaları
| Datasheet | MODEL | Debi [m3/h] 50/60 Hz | Vakum [mbar rel.] 50/60 Hz | Motor Gücü [KW] 50/60 Hz |
|---|
|
|
|
|
||
|---|---|---|---|---|
|
O 5.4 | 4,0/4,8 | -998,0/-998,0 | 0,1/0,12 |
|
O 5.6 | 3,0/3,0 | -997,0/-997,0 | 0,3/0,36 |
 |
O 5.8 | 8,0/9,6 | -998,0/-998,0 | 0,35/0,45 |
| Datasheet | MODEL | Debi [m3/h] 50/60 Hz | Vakum [mbar rel.] 50/60 Hz | Motor Gücü [KW] 50/60 Hz |
|---|
|
|
|
|
||
|---|---|---|---|---|
|
U 4.20 | 18/21 | <-999,0/<-998,5 | 0,55/0,66 |
|
U 4.40 | 41/48 | -999,5/-999,5 | 1,50/1,80 |
| Datasheet | MODEL | Debi [m3/h] 50/60 Hz | Vakum [mbar rel.] 50/60 Hz | Motor Gücü [KW] 50/60 Hz |
|---|
|
|
|
|
||
|---|---|---|---|---|
|
U 5.70 | 70/84 | <-999,9/<-999,9 | 1,5/1,8 |
|
U 5.100 | 100/120 | <-999,9/<-999,9 | 2,2/2,6 |
|
U 5.165 | 165/198 | <-999,9/<-999,9 | 3,0/3,6 |
|
U 5.200 | 200/240 | <-999,9/<-999,9 | 4,0/4,8 |
|
U 5.300 | 300/360 | -999,9/-999,9 | 5,5/6,6 |
| Datasheet | MODEL | Debi [m3/h] 50/60 Hz | Vakum [mbar rel.] 50/60 Hz | Motor Gücü [KW] 50/60 Hz |
|---|
|
|
|
|
||
|---|---|---|---|---|
|
U 5.70 O2-PACK | 70/84 | <-999,5/<-999 | 1,5/1,8 |
|
U 5.100 O2-PACK | 100/120 | <-999,5/<-999 | 2,2/2,6 |
|
U 5.165 O2-PACK | 165/198 | <-999,5/<-999 | 3,0/3,6 |
|
U 5.200 O2-PACK | 200/240 | <-999,5/<-999 | 4,0/4,8 |
|
U 5.300 O2-PACK | 300/360 | <-999,5/<-999 | 5,5/6,6 |
| Datasheet | MODEL | Debi [m3/h] 50/60 Hz | Vakum [mbar rel.] 50/60 Hz | Motor Gücü [KW] 50/60 Hz |
|---|
|
|
|
|
||
|---|---|---|---|---|
|
U 4.400 SA/K | 435/508 | -997,0/-997,0 | 11,0/12,5 |
|
U 4.400 F/K | 435/508 | -999,5/-999,5 | 11,0/12,5 |
|
U 4.630 SA/K | 624/732 | -997,5/-997,5 | 15,0/18,5 |
|
U 4.630 F/K | 624/732 | -999,5/-999,5 | 15,0/18,5 |
BECKER Vakum Kuru Tip Vakum Pompaları
| Datasheet | MODEL | Debi [m3/h] 50/60 Hz | Vakum [mbar rel.] 50/60 Hz | Motor Gücü [KW] 50/60 Hz |
|---|---|---|---|---|
|
VT 4.2 | 1,9/2,3 | -600/-600 | 0,09/0,105 |
|
VT 4.4 | 4,1/4,7 | -850/-850 | 0.18/0.21 |
|
VT 4.8 | 8/9.1 | -850/-850 | 0.37/0.44 |
|
VT 4.10 | 10/12 | -850/-850 | 0.37/0.45 |
|
VT 4.16 | 16/19 | -850/-850 | 0.55/0.7 |
|
VT 4.25 | 25/30 | -850/-850 | 0.75/0.9 |
|
VT 4.40 | 40/48 | -850/-850 | 1.25/1.5 |
|
VX 4.10 | 10/12 | -900/-900 | 0.37/0.45 |
|
VX 4.16 | 16/19 | -900/-900 | 0.55/0.7 |
|
VX 4.25 | 25/30 | -900/-900 | 0.75/0.9 |
|
VX 4.40 | 40/48 | -900/-900 | 1.25/1.5 |
| Datasheet | MODEL | Debi [m3/h] 50/60 Hz | Vakum [mbar rel.] 50/60 Hz | Motor Gücü [KW] 50/60 Hz |
|---|
|
|
|
|
||
|---|---|---|---|---|
|
KVT 3.60 | 55/66 | -900/-900 | 2,40/3,00 |
|
KVT 3.80 | 67/78,5 | -900/-900 | 2,40/3,00 |
|
KVT 3.100 | 98/112 | -900/-900 | 3,00/3,50 |
|
KVT 3.140 | 132/154 | -900/-800 | 4,00/4,80 |
|
KVX 3.60 | 55/66 | -900/-900 | 2,40/3,00 |
|
KVX 3.80 | 67/78,5 | -900/-900 | 2,40/3,00 |
|
KVX 3.100 | 98/112 | -900/-900 | 3,00/3,50 |
|
KVX 3.140 | 132/154 | -900/-800 | 4,00/4,80 |
| Datasheet | MODEL | Debi [m3/h] 50/60 Hz | Vakum [mbar rel.] 50/60 Hz | Motor Gücü [KW] 50/60 Hz |
|---|
|
|
|
|
||
|---|---|---|---|---|
|
KVT 3.80/0-400 | 76 | -900 | 4,00 |
|
KVT 3.100/0-400 | 112 | -900 | 4,00 |
|
KVT 3.140/0-400 | 145 | -900 | 4,00 |
|
KVX 3.80/0-400 | 76 | -900 | 4,00 |
|
KVX 3.100/0-400 | 112 | -900 | 4,00 |
|
KVX 3.140/0-400 | 145 | -900 | 4,00 |
| Datasheet | MODEL | Debi [m3/h] 50/60 Hz | Vakum [mbar rel.] 50/60 Hz | Motor Gücü [KW] 50/60 Hz |
|---|
|
|
|
|
||
|---|---|---|---|---|
|
VTLF 2.200 | 178/218 | -800/-800 | 4,00/4,80 |
|
VTLF 2.250 | 244/286 | -800/-800 | 5,50/6,40 |
|
VTLF 2.360 | 351/402 | -750/-750 | 11,0/13,2 |
|
VTLF 2.400 | 390/460 | -800/-800 | 7,5/8,6 |
|
VTLF 2.500 | 495/570 | -750/-750 | 11,0/12,6 |
|
VXLF 2.200 | 178/218 | -800/-800 | 4,00/4,80 |
|
VXLF 2.250 | 244/286 | -800/-800 | 5,50/6,40 |
|
VXLF 2.400 | 390/460 | -800/-800 | 7,5/8,6 |
|
VXLF 2.500 | 495/570 | -750/-750 | 11,0/12,6 |
| Datasheet | MODEL | Debi [m3/h] 50/60 Hz | Vakum [mbar rel.] 50/60 Hz | Motor Gücü [KW] 50/60 Hz |
|---|
|
|
|
|
||
|---|---|---|---|---|
|
VTLF 2.250/0-400 | 280 | -800 | 7,50 |
|
VTLF 2.360/0-400 | 405 | -750 | 13,2 |
|
VTLF 2.500/0-400 | 560 | -750 | 11,0 |
|
VXLF 2.250/0-400 | 280 | -800 | 7,50 |
|
VXLF 2.500/0-400 | 560 | -750 | 11,0 |
